Bently Nevada 330103-00-05-50-12-00 3300 XL 8mm Tip Diameter Proximity Probe with 5.0 Meter System Length and API 670 Compliance

Brand Name : Bently Nevada

Model Number : 330103-00-05-50-12-00

Place of Origin : USA

MOQ : 1

Price : 66USD

Payment Terms : T/T

Supply Ability : in stock

Delivery Time : 2-3 work days

Packaging Details : Brand new and original

Model : 330103-00-05-50-12-00

Country of origin : USA

Place of shipment : Xiamen,China

Shipping : TNT, DHL, FedEx, EMS, UPS

MOQ : 1 piece

Packaging : Original new packaging

Contact Now

Bently Nevada 330103-00-05-50-12-00 3300 XL 8 mm Proximity Probe
Bently Nevada 330103-00-05-50-12-00 3300 XL 8mm Tip Diameter Proximity Probe with 5.0 Meter System Length and API 670 Compliance

The Bently Nevada 330103-00-05-50-12-00 is a high-reliability 3300 XL 8mm proximity probe designed for non-contact shaft displacement measurement and radial vibration monitoring in critical rotating machinery. As a core component of API 670 compliant protection systems, it ensures maximum uptime for steam turbines, compressors, and pumps.

  • High-Precision Monitoring: Engineered for axial thrust position and shaft vibration monitoring, delivering a stable scale factor of 7.87 V/mm (200 mV/mil) calibrated for AISI 4140 steel.
  • Rugged Mechanical Design: Features a fully threaded M10 x 1 metric thread probe (50mm case length / 0mm unthreaded) for precise gapping and easy installation.
  • FluidLoc & ClickLoc Technology: Equipped with a miniature coaxial ClickLoc connector and an advanced FluidLoc cable that stops oil and process fluids from leaking through the wire strands.
  • 5-Meter System Length: Unarmored 5.0-meter configuration designed for direct, seamless integration with Bently Nevada 3500 rack modules and 3300 XL Proximitor sensors.
Bently Nevada 330103-00-05-50-12-00 3300 XL 8mm Tip Diameter Proximity Probe with 5.0 Meter System Length and API 670 Compliance
  • Immediate Shipping (Minimize Your Downtime)
  • Huge Stock of Bently Nevada Series
  • 100% Inspected with 1-Year Warranty
  • Global Shipping to 160+ Countries
Need an Instant Quote?
Contact: Miya Zheng
Email: sales@amikon.cn
WhatsApp: +86 180 2077 6792
Bently Nevada 330103-00-05-50-12-00 3300 XL 8mm Tip Diameter Proximity Probe with 5.0 Meter System Length and API 670 Compliance
Technical Specifications
Parameter Value
Product Series Bently Nevada 3300 XL 8 mm
Part Number 330103-00-05-50-12-00
Thread Type M10 x 1 metric thread
Mounting Option Forward mount
Unthreaded Length (00) 0 mm
Overall Case Length (05) 50 mm
Total System Length (50) 5.0 meters
Cable Armor Unarmored
Linear Range 2.0 mm
Scale Factor 7.87 V/mm
Calibration Target AISI 4140 steel
Connector Type (12) Miniature coaxial ClickLoc connector
Cable Feature FluidLoc cable
Agency Approvals (00) Not required
Bently Nevada 330103-00-05-50-12-00 3300 XL 8mm Tip Diameter Proximity Probe with 5.0 Meter System Length and API 670 Compliance
Frequently Asked Questions
Q1: What are the exact physical dimensions and thread specifications of the Bently Nevada 330103-00-05-50-12-00 proximity probe?
A: The 330103-00-05-50-12-00 is a 3300 XL 8 mm probe, forward mount, M10 x 1 thread. Pretty standard. “00” means no unthreaded section, fully threaded body. “05” gives 50 mm case length. In most cases it’s just treated as a 5.0 m system length probe.
Q2: Does the Bently Nevada 330103-00-05-50-12-00 probe require an external extension cable for system integration?
A: No. It already comes as a 5.0 meter system length, so it connects directly to a 3300 XL Proximitor sensor like 330180-50 series. No extension cable in between. People usually don’t add one anyway, since changing length can affect calibration a bit in radial vibration monitoring or shaft displacement measurement.
Q3: What specific cable and connector technologies are utilized in the 330103-00-05-50-12-00 model?
A: It uses “12” ClickLoc connector with FluidLoc cable. Not much to explain here. FluidLoc just blocks oil or moisture from moving through the cable. Common in industrial rotating machinery, where contamination shows up often. Helps keep eddy current sensor signals stable.
Q4: What are the calibration and measurement standards for the Bently Nevada 330103-00-05-50-12-00?
A: Used for non-contact shaft displacement, also radial vibration monitoring, sometimes axial thrust position. Calibration on AISI 4140 steel target. Range about 2.0 mm (80 mils), sensitivity 200 mV/mil (7.87 V/mm). Fits directly into API 670 system with Bently Nevada 3500 system, no extra setup.
Q5: What hazardous area certification does the 330103-00-05-50-12-00 probe hold?
A: “00” means no hazardous approvals. So only standard industrial use. For ATEX / IECEx / CSA, you need a different variant, especially for refinery or ESD systems. This one is just normal 3300 XL 8 mm probe type.
Bently Nevada 330103-00-05-50-12-00 3300 XL 8mm Tip Diameter Proximity Probe with 5.0 Meter System Length and API 670 Compliance
Bently Nevada 330103-00-05-50-12-00 3300 XL 8mm Tip Diameter Proximity Probe with 5.0 Meter System Length and API 670 Compliance
Compatible Parts and Accessories
Part Number Compatible With
330703-000-060-10-02-00 3500/92
106M1081-01 330103-00-05-10-02-00
3500/42M 176449-02 330703-000-060-10-02-00
3500/15 AC 127610-01 330103-00-09-10-02-00
128276-01E 131151-01 135813-01
18745-04 990-05-XX-01-00
330102-22-58-10-02-00 330180-X1-05 MOD:145004-02
330910-03-09-05-02-05 133323-01
330709-000-070-10-02-00 330905-00-08-10-02-00
3500/61 163179-02 990-04-50-01-00
1900/65A 172323-01/1900/65A 167699-02 330101-XX-XX-10-02-05 MOD:147773-00-12
3500/15 106M1079-01 330104-00-04-10-02-00
3500/65 145988-02 330104-00-06-10-02-00
3500/92 136180-01 330851-04-000-023-10-01-05
3500/94 145988-01 330910-05-10-02-00
330104-00-10-10-02-05 330101-00-16-10-02-00
330910-00-05-10-02-00 3300/12
3500/44M 176449-03 330850-50-05
TK3-2E 14700-02A 330730-080-00-00
3500/42M 140734-02 330930-040-01-00
